1. Optical system: Infinity optical system.
2. Total magnification: 50X-800X.
3. Eyepiece: Wide field plan eyepiece WF10X (Φ22mm).
4. Objective: Infinite long working distance plan apochromatic objective PLL5X/PLL10X/PLL20X/PLL50X/PLL80X.
5. Observation head: Hinged, inclined 30°, rotatable 360°, trinocular head.
6. Nosepiece: Five-hole (inward-facing ball positioning).
7. Stage: Double-layer mechanical movable large platform: 280mm×270mm, travel range: 204mm×204mm.
8. Illumination system: 5W high - brightness LED for reflected light, adjustable brightness, with built - in field diaphragm; 5W high - brightness LED for transmitted light, adjustable brightness.
9. Camera: MSD-2000
10. Resolution: 20 million pixels
11. Sensor size: 1" inches
Pakage :
- 1pcs/ctn 580X520X490mm
- GW：18.9kg
