1. Optical system: Infinity optical system.
2.Total magnification: 40X-1000X.
3. Eyepiece: Wide field plan eyepiece WF10X (Φ20mm).
4. Objective: Infinity semi-plan achromatic objective 4X, 10X, 40X (S), 100X (S/oil).
5. Observation head: Hinged, tilted at 30°.
6. Nosepiece: Four-hole (inward-facing ball positioning).
7. Stage: Double-layer mechanical movable, size: 210X140mm, travel: 80mmX50mm.
8. Illumination system: 3W LED, adjustable brightness.
9. Camera: MSD-2000
Pakage :
- 1pcs/ctn 520X365X750mm
- GW：11.5kg
