1. Optical system: Infinity optical system.
2. Total magnification: 40X-1000X.
3. Eyepiece: Wide field plan eyepiece WF10X (Φ23mm).
4. Objective: Plan achromatic objective 4X/10X/20X/40X/100X.
5. Observation head: Hinged, inclined 30°, trinocular head.
6. Nosepiece: Five-hole (inward-facing ball positioning).
7. Stage: Double-layer mechanical loading platform size: 210×140mm, travel: 80×50mm.
8. Fluorescence excitation channels:
- Blue light: Ex 410nm~490nm
- Green light: Ex 475nm~550nm
9. Illumination system: Reflected light LED and transmitted light LED, both with adjustable brightness.
Pakage :
- 1pcs/ctn 520X325X750mm
- GW：12.3kg
