Inverted Metallographi c Microscope.
+2000W
Pixels Camera
1. Optical system: Finite far-optical system
2. Total magnification: 100X-1000X.
3. Eyepiece: Wide field plan eyepiece WF10X (Φ18mm).
4. Objective: Plan achromatic objective 10X/PL20X/PL40X (spring)/PL100X (spring, oil).
5. Observation head: Hinged, inclined 30°, rotatable 360°, trinocular head.
6. Nosepiece: Four-hole (inward-facing ball positioning).
7. Stage: Double-layer mechanical movable, size: 180mm×150mm, travel range: 15mm×15mm.
8. Illumination system: Halogen lamp, adjustable brightness with variable aperture.
