1.Optical system: Infinity optical system.
2. Total magnification: 50X-500X.
3. Eyepiece: Wide field plan eyepiece WF10X (Φ22mm).
4. Objective: Plan achromatic objective PLL5X/PLL10X/PLL20X/PLL50X.
5. Observation head: Hinged, inclined 30°, trinocular head.
6. Nosepiece: Five-hole (inward-facing ball positioning).
7. Stage: Double-layer mechanical movable large platform, size: 185mm×140mm, travel: 35mm×30mm.
8. Illumination system: Reflected light halogen lamp, adjustable brightness.
Pakage :
- 1pcs/ctn 380X360X630mm
- GW：20kg
